Legend:
l – length of bolt
d – the nominal diameter of the thread
k – head height
dk – head diameter
Makings:
Steel: 370HV
Stainless: A2
Table according to DIN 7500:
| D | M2 | M2,5 | M3 | M4 | M5 | M6 | M8 |
| m | 0 | 1 | 1 | 2 | 2 | 3 | 4 |
| dk max. | 4 | 5 | 6 | 8 | 10 | 12 | 16 |
| k max. | 1,6 | 2 | 2,4 | 3,1 | 3,8 | 4,6 | 6 |
